Sludge Silos
Reliable Sludge Silos for Efficient Storage and Discharge
Finmatec develops and manufactures high-performance sludge silos designed for safe, hygienic and controlled handling of centrifuged sludge in wastewater treatment plants and industrial processing facilities. Our proven sliding frame technology ensures consistent FIFO discharge even at high dry solids content – up to 40 %.
Thanks to our in-house expertise in mechanical design, automation, and installation, we deliver turnkey sludge storage solutions tailored to your process – from the initial design to commissioning and service support.
Finmatec sludge silos offer low cost of ownership and long-term performance you can rely on.
Low cost of ownership
Sludge discharge as FIFO
Easy to operate by Siemens touch panel
Robust and well proven technology
Tailor made solutions upon request
Turnkey deliveries
Warranty 24 months as standard
FINMATEC SLUDGE SILOS
Silos ranging from diameter 3.500 mm to 5.000 mm can be offered as standard with volumes from 50 m3 even up to about 400 m3.
Other sizes offered upon request. The unique sliding frame technology developed by Finmatec, is a well proven method of discharging centrifuged sludge with DS up to even 32 %.
The sliding frame combined with a robust and speed controllable screw conveyor in Finmatec sludge silos, ensures that sludge is discharged as first-in-first-out (FIFO) with a capacity of up to 100 m3/h. Both sliding frame and the bottom gate is controlled by a hydraulic unit. In case of a electrical failure, the gate is automatically closed by a UPS battery. A main electrical cabinet and a local control panel comes as option.
The whole operation is easy to control with a Siemens CPU touch screen. Several different interfaces can be offered such as Profinet, Profibus or Ethernet, thus giving the possibility to follow the process from the control room. The surface treatment combined with the robust well proven technology ensures that a Finmatec sludge silo system will last for decades. A warranty of 24 months is offered as standard. The inhouse knowhow, starting from mechanical and electrical design, strength calculation, manufacturing & testing, as well as transport, installation and
commissioning is fully controlled and offered by Finmatec. Service contracts is offered upon request.
Finmatec experience
Finmatec has over 30 years of experience in designing and manufacturing equipment for Waste Water Treatment Plants. Over 40 projects have been installed in mainly Scandinavia, Estonia and Brazil. Thanks to the long experience and great know-how in designing and manufacturing tailor-made equipment for storage and discharge of centrifuged sludge, the solutions from Finmatec is today recognized as the most advanced systems on the market. The working principle of the Push Floor Discharger in combination with an efficient Screw Conveyor, is what sets us apart from similar systems being offered on the market. Finmatec offers the whole range starting from design and manufacturing, including Automation and PLC as well as installation, commissioning, technical support and after sales services.
The most efficient discharge on the market
“Years of experience and dedicated work is the key to the reliability and efficiency of our discharge sludge solutions.”
Anders Asplund CEO Finmatec Oy Ab
